Test item
|
Symbol
|
Range
|
Open / Short
|
os
|
200Ω ~ 50KΩ
|
Conductance
|
Cond.
|
1mΩ ~ 50Ω
|
Resistance
|
R
|
0.1Ω ~ 1MΩ
|
Capacitance
|
C
|
10pF ~ 500uF
|
Capacitance Polarity polaritypolarity
|
±
|
|
Zener
|
D
|
0 ~ 7V
|
Dc Insulation
|
Is.
|
1MΩ ~ 1000MΩ
|
Ac Hipot
|
IL
|
0.01mA ~ 5mA
|
Arcing
|
|
0 ~ 8 ( 0 , off )
|
Intermittent
Conductance
|
Int.cond.
|
1mΩ ~ 50Ω
|
Intermittent
Open/Short
|
Int.os
|
200Ω-50KΩ
|
Test information
|
Output Rating 5 Vdc , 20mA max
DC Hipot / insulation 5-1000V
AC Hipot / 50-700V (50V Resolution)
|
Test mode
|
NORMAL / S.SIDE / S.STEP
Rated current & voltage analysis
|
Communication interface
|
Handler / Rs232 / Print / USB
|
Measurement& scanning Mode
|
Series
/ Parallel
Auto/Short
Switchable
|
Decision mode
|
Pass /fail (led) .
Speaker
|
Lock Mode
|
Standard lock /
Password lock
|
Starting
mode
|
Auto / Manual / Continuous /
External
|
Memory
|
1024KB
|
Comprehensive information
|
Power Input 220V ±10% 60Hz
(Option 110V 50Hz)
Power
consumption: 100W
Temp. : -10℃ ~ 35℃ Humidity
: RH≤ 75%
Size :
425*190*350 (64p or 128P) / 425*240*350 (256P)
Weight :
13KG(64p) / 14KG(128p) / 18KG(256p)
Display 320*240 led
|
